Jual gps geodetic geofennel fgs 1
Gambar Produk
Jual gps geodetic geofennel fgs 1
Brand
GEO FENNEL
Minimum Pembelian
1 Set
Maximum Pembelian
15 Set
Pengiriman
1 Hari Setelah Pembayaran
Lokasi
Harga
Rp. 10.000
Dilihat Sebanyak
118 kali
Update Terakhir
04-05-2016
Bagikan
+ Penawaran
Perhatian!
Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.
Spesifikasi Jual gps geodetic geofennel fgs 1
GPS GEODETIC Geofennel FGS 1 , ,081333102011
Features
High speed processing
Support for both post-processing and kinematic
Processing ability separate or to be combined with GPS, GLONASS and BeiDou
Supports downloads & use of precise ephemeris
Generation of various reports
User friendly
Supplied with
GPS SYSTEM FGS 1 COMPLETE SET
ART.-NO. 751000
2 GNSS Antenna FGS 1
1 MicroSurvey Fieldgenius Software
1 Fieldcontroller DC5
1 Postprocessing Software
2 USB-Cable for FGS 1
2 RS-232 Cable for FGS 1
1 Measuring Tape 3 m
1 Tribrach AJ 10 black
1 Tribrach Adaptor AL 11-D black with optical plummet
1 Container
1 Operators‘ manual
GPS SYSTEM FGS 1 NETZWERK-SET
ART.-NO. 750100
1 GNSS Antenna FGS 1
1 MicroSurvey Fieldgenius Software
1 Fieldcontroller DC5
1 Postprocessing Software
1 USB-Cable for FGS 1
1 RS-232 Cable for FGS 1
1 Measuring Tape 3 m
1 Container
1 Operators‘ manual
Technical data
| Signal Tracking | |
| 256 channels with simultaneously tracked satellite signals: | |
| - GPS | L1 C/A, L1/L2P, L5 |
| - GLONASS | L1/L2 |
| - BeiDou | B1, B2, B3 |
| - Galileo | Yes, but not activated |
| - SBAS | WAAS, EGNOS, MSAS |
| Performance Specifications | |
| Cold start | <50s |
| Warm start | <30s |
| Initialization time | typically <10s |
| Initialization reliability | typically >99,9% |
| Signal reacquisition | <2s |
| Positioning Specifications | |
| Post processing static | |
| - horizontal | 2,5 mm + 0,5 ppm RMS |
| - vertical | 5,0 mm + 0,5 ppm RMS |
| Real time kinematic | |
| - horizontal | 10 mm + 0,5 ppm RMS |
| - vertical | 20 mm + 0,5 ppm RMS |
| E-RTK (<100 km) | |
| - horizontal | 0,20 m + 1 ppm RMS |
| - vertical | 0,40 m + 1 ppm RMS |
| Code differential GNSS positioning | |
| - horizontal | 0,25 m + 1 ppm RMS |
| - vertical | 0,50 m + 1 ppm RMS |
| SBAS | typically <1 m 3D RMS |
| Stand-Alone | <1,5 m RMS |
| Communication | |
| 1 Serial port (7 Pin Lemo), Baud rates up to 921 600 bps | |
| Radio modem (optional) | Tx/Rx with full frequency rang from 410 – 470 MHz |
| - transmit power | 0.5 – 2W adjustable |
| Positioning update rate | 1 Hz, 2 Hz, 5 Hz, 10 Hz |
| 5 LED Indicating lights | Power, satellite tracking, differential data and data recording |
| Bluetooth®; V 2.X protocol, work compatible with Windows 7®, Windows mobile® and Android® | |
| Data Format | |
| Data inputs / outputs | |
| - Correction data I/O | RTCM 2.x, 3.x, CMR & CMR+ (GPS only) |
| Position data outputs | |
| - ASCII | NMEA-0183 GSV, RMC, HDT, VHD, GGA, GSA, ZDA, VTG, GST, PJK, PTNL |
| geo-FENNEL Binary update to 20 Hz | |
